Zero Balance Accuracy Level Rated Output 75T Beam Type Load Cell

Detail Information

Product Name:	75t Beam Type Load Cell	Range:	6,8,12,16,35,50,75(t)
Rated Output:	Accuracy Level	Temp. Compensated:	-10ºC To + 40ºC
Communication:	RS232/485	Material:	Aluminum Alloy
High Light:	75T Beam Type Load Cell , Zero Balance Beam Load Cell , Accuracy Level Beam Type Load Cell

Product Description

Zero Balance Accuracy Level Rated Output 75t beam type load cell

APPLICATIONS

Assembly Forces

Physical Therapy Devices

Patient Weight

Hand Tool Forces

Chiropractic and Exercise Equipment

Consumables Monitoring: Copy Equipment

and Vending systems

Appliance Payload Monitoring: Washers,

Dryers, Water Weight, Extraction Efficiency Appliance Unbalance Monitoring

Product parameters:

6,8,12,16,35,50,75(t) (Customizable range)

Rated Output		2.0mV/V ±10%
Zero Balance		±3% of rated output
Creep after 30 minutes		±0.03% of rated output
Nonlinearity		±0.03% of rated output
Hysteresis		±0.03% of rated output
Repeatability		±0.03% of rated output
Temp. effect on output		≤0.002% of applied output/ºC
Temp. effect on zero		≤0.002% of rated output/ºC
Safe Temp. Range		-10ºC to + 70ºC
Temp. Compensated		-10ºC to + 40ºC
Safe Overload		150%
Input Impedance		410 ohm ± 20 ohm
Output Impedance		350 ohm ± 5 ohm
Insulation Resistance		≥5000 M ohm (50V DC)
Rated Excitation		10V DC/AC
Maximum Excitation		15V DC/AC
Cable Length		13cm/35cm/275cm
Cable Color Code		Red(+E) Black(-E) Green(+S) White(-S)

Product Size:

此图纸是6t的量程
